| SPECIFICATIONS:
Holding Torque....... 175 oz-in
Rotor Inertia.......... 1.64 oz-in2
Step Angle............... 1.8 deg
Weight.................... 1.54 lbs
|
Parallel |
Series |
Half Coil |
| Resistance |
3.6 ohms |
14.4 ohms |
7.2 ohms |
| Rated Current |
1.41 amps |
0.71 amps |
1.0 amps |
| Rated Voltage |
5.1 volts |
10.2 volts |
7.2 volts |
| Inductance |
11.0 mH |
44.0 mH |
11.0 mH |
|
MOTOR POWER CONNECTORS:
|
|
|
| 5 pin female DIN connector-front
view |
4 pin female circular connector-front view
cable length-10' standard |
|
