SPECIFICATIONS:
Holding Torque........ 1618 oz-in
Rotor Inertia.............. 49.2 oz-in2
Amps
Step Angle............... 1.8 deg.
|
Parallel |
Series |
Half Coil |
Resistance |
.1225 ohms |
.49 ohms |
.245 ohms |
Rated Current |
12.3 amps |
6.15 amps |
8.7 amps |
Rated Voltage |
1.5 volts |
3.0 volts |
2.13 volts |
Inductance |
1.3 mH |
5.2 mH |
1.3 mH |
|
MOTOR POWER CONNECTORS:
|
|
Motor rear view
with end cap removed |
4 pin female circular
connector-front view cable length-10' standard |
|
