Superdrive

FEATURES:

Completely wired and tested system Emergency stop and lighted power switch Bicolored LEDs to indicate motion and output status Solid state relays for AC control Built-in cooling fan Toroidal transformer for compact overall profile

SuperDrive is a complete power driver subsystem with built in power supply and drivers for up to 3 stepper motors and 2 software controlled AC outlets. This controller is equipped with output status indicators and an emergency stop button. When used with the OptiStep Plus Motion Controller, the SuperDrive provides affordable, efficient motion control for stepper motors from 30 to 450 oz-in. Maximum output is 3.5 amps per phase for halfstep model and 5.0 amps per phase for microstepping model, both at 40VDC. Complete packages including the OptiStep motion controller, SuperScribe software, computer cable and motor cables are listed below for ordering convenience and cost savings.
