| SPECIFICATIONS:
Holding Torque........ 53 oz-in
Rotor Inertia....... 0.547 oz-in
Amps
Step Angle............... 1.8 deg.
Weight...................... 1.17 lbs
|
Center Tap |
Series |
| Resistance |
5.1 ohms |
10.2 ohms |
| Rated Current |
1.0 amps |
0.71 amps |
| Rated Voltage |
5.1 volts |
7.2 volts |
| Inductance |
10 mH |
40 mH |
|
MOTOR POWER CONNECTORS:
|
|
|
|
5 pin female DIN connector-front view
|
4 pin female circular connector-front view
cable length-10' standard
|
|
