| SPECIFICATIONS:
Holding Torque....... 220 oz-in
Rotor Inertia.......... 3.66 oz-in2
Step Angle............... 1.8 deg.
Weight....................... 3.0 lbs
|
Parallel |
Series |
Half Coil |
| Resistance |
.19 ohms |
.76 ohms |
.38 ohms |
| Rated Current |
6.6 Amps |
3.3 Amps |
4.7 Amps |
| Rated Voltage |
1.27 volts |
2.5 volts |
1.8 volts |
| Inductance |
1.25 mH |
5.0 mH |
1.25 mH |
|
MOTOR POWER CONNECTORS:
|
|
|
4 pin female circular connector-front view
cable length-10' standard
|
|
