| SPECIFICATIONS:
Holding Torque....... 450 oz-in
Amps
Rotor Inertia.......... 10.2 oz-in
Step Angle............... 1.8 deg.
Weight....................... 7.7 lbs
|
Center Tap |
Series |
| Resistance |
1.22 ohms |
2.44 ohms |
| Rated Current |
3.5 amps |
2.47 amps |
| Rated Voltage |
4.3 volts |
6.1 volts |
| Inductance |
7.0 mH |
28 mH |
|
MOTOR POWER CONNECTORS:
|
|
|
4 pin female circular connector-front view
cable length-10' standard
|
|
