SPECIFICATIONS:
Holding Torque....... 4000 oz-in
Rotor Inertia.............. 88.6 oz-in2
Step Angle.................. 1.8 deg
Weight........................... 25 lbs
| Resistance |
0.67 ohms
|
| Rated Current |
8.0 Amps
|
| Rated Voltage |
5.37 volts
|
| Inductance |
11 mH
|
|
MOTOR POWER CONNECTORS:
|
|
|
4 pin female circular connector-front view
cable length-10' standard
|
|
